Pulsar Merger LRF XP50 Pro Thermal Imaging Binoculars

Pulsar Merger LRF XP50 Pro Thermal Imaging Binoculars

Regular price R 119,999.00 ZAR
Regular price R 0.00 ZAR Sale price R 119,999.00 ZAR
Sale Sold out
Taxes included. Shipping calculated at checkout.
  • F50/1.0 OBJECTIVE LENS
  • 640X480 PIX. @ 17 MICRON
  • 50HZ REFRESH RATE
  • 1800M DETECTION RANGE
  • 2.5 - 20 (X8 ZOOM) MAGNIFICATION
  • 1000M LASER RANGEFINDER
  • FULL-COLOUR AMOLED DISPLAY
  • SENSOR SENSITIVITY < 25MK NETD
  • COMFORTABLE FOR LONG OBSERVATION
  • IMAGE DETAIL BOOST FUNCTION
  • IPX7 WATERPROOF RATED
  • QUICK-CHANGE HIGH CAPACITY BATTERY

DESCRIPTION

The Pulsar Merger LRF XP50 Pro Thermal Imaging Binoculars are built with the classic design of daytime binoculars. With a small form factor, these thermal imaging binoculars fit comfortably in the hand, but still offer appealing external aesthetics and exemplary ergonomics. The six function buttons are placed in the comfort access zone and the most used digital device functions are activated with a single touch.

The Merger LRF binoculars optical design fully takes into account the nature of human vision. It is natural for a person to receive visual information through two visual channels simultaneously. Viewing with two eyes is less tiring than viewing with one. This means better detection of small or faint objects, and better performance in low-contrast scenarios than similar monocular thermal imaging devices with the same technical level. The interpupillary distance in the Merger LRF binoculars is adjustable from 56 to 71 mm in accordance with the individual characteristics of a particular user.

Understanding the target distance is an essential factor in making the right decisions. A built-in laser rangefinder with a range of up to 1 kilometre allows you to measure distances in single measurements and continuous scanning modes with an accuracy of 1 meters for quick and error-free assessment of the situation. A high sensitivity sensor with < 25 mK NETD captures minimal temperature differences when observing in conditions of low temperature contrast, as well as during rain or fog. The 640x480 pixel resolution ensures reliable identification of the target, high-quality visualisation of important anatomical features of the animal plus minute details of the surrounding landscape.

The characteristics of thermal imaging optics have a decisive influence on a thermal imagers ability to capture even the lowest radiation levels. Ultimate detection efficiency is achieved with the fast lens of the Merger LRF (F50/1.0) thermal imager in combination with the highly sensitive thermal sensor. The Merger LRF gives users the best quality, most detailed & high-contrast, informative imagery every time, even during rain or fog, when the temperature contrast of the observed scene is minimal. The Merger LRF thermal imaging binoculars are equipped with advanced image processing algorithms that show their effectiveness under different weather conditions and device operation scenarios. With the Merger LRF eyepieces, the user receives a new level of clear and noise-free imaging, with increased object details and improved contrast.

The Merger LRF is powered with two rechargeable batteries: one built-in with a capacity of 4 Ah, the other replaceable with a capacity of 3.2 Ah. A single charge guarantees up to 10 hours of battery life. The embossment on the body of the replaceable battery for accurate determination of the correct position makes it possible to quickly and confidently replace a flat battery with a new one in complete darkness by touch. A powerful long-distance objective lens combined with a 640x480@17m highly-sensitive thermal imaging sensor provides exceptional detection capabilities. A standard 1.8m tall object can be detected up to 1800 m away in complete darkness.



FEATURES

  • 2.5-20x variable magnification
  • High-quality reinforced magnesium alloy housing
  • Built-in photo and video recorder
  • Stream Vision 2. Wi-Fi integration with iOS and Android devices
  • Improved Wi-Fi connectivity with 2.4 / 5 GHZ waveband support
  • High-contrast HD AMOLED displays
  • IPX7 Waterproof Rated
  • Wide range of operating temperatures (-25 to +50C)
  • A selection of 8 color palettes



SPECIFICATIONS

Main
Sensor 640x480 @ 17 m (NETD <25 mK)
Objective lens F50/1.0
Magnification, x 2.5 20 (x8 zoom)
Field of view (HxV), degrees / m@100m 12.4x9.3 / 21.8x16.3
Detection range, m 1800
Sensor
Type uncooled
Resolution, pixels 640x480
Pixel pitch, m 17
NETD, mK <25
Frame rate, Hz 50
Optics
Objective lens F50/1.0
Magnification, x 2.5 20
Field of view (HxV), degrees / m @ 100 m 12.4x9.3 / 21.8x16.3
Interpupillary distance adjustment, mm 56 - 71
Eye relief, mm 15
Display
Type AMOLED HD
Resolution, pixels 1024x768
Range Performance
Detection range, m 1800
Laser Rangefinder
Safety class for laser equipment according to IEC 60825-1:2014 1
Wavelength, nm 905
Max. measuring range, m 1000
Measurement accuracy, m 1
Video Recorder
Video / photo resolution, pixel 1024x768
Video / photo format .mp4 / .jpg
Built-in memory, GB 16
Built-in memory capacity -
Wi-Fi
Wireless Protocol Wi-Fi
Wireless Standard IEEE 802.11 b/g/n/ac (WPA)
Frequency, GHz 2.4 / 5
Environmental Characteristics
Degree of protection, IP code (IEC60529) IP7 (waterproof)
Operating temperature range, -25 +50
Connections and Compatibilities
Mount, type 1/4" socket
Supported Application Stream Vision 2
Power Supply
Output voltage, V 3.7
Battery type Dual Li-Ion Power System: 3.2 Ah Changeable Battery (external) / 4.0 Ah Battery (internal)
Capacity, mAh 3200 (external) + 4000 (internal)
Operating time on battery pack (at t22C), h 10
External power supply, V 5 (USB Type C)
Weight & Size
Body material Magnesium alloy
Dimensions, mm 196x143x76
Weight, kg 0.8
